Item No. | Y10D-20 |
Pixels | 1080P . (It Also Has 720P Can Be Choosed ) |
CPU | XM530 |
Sensor | Sensor F37
|
Lens | Interface: M12; Lens: Megapixel Fixed Focus Lens; Focal Length: 3.6MM |
Operating System | Embedded Linux Operating System |
Video Processing | H.264 High Profile+/ H.264 Main Profile+/ H.264 Base Line Profile+ |
Connection Mode | Wireless Connection |
Wireless Connection | IEEE 802.11b/g/n; 2.4GHz Supports WEP, WPA And WPA2 Encryption |
Antenna Mode | Built In Wireless Antenna |
Audio Input | Built In Microphone G.711A Standard |
Audio Output | Built In 1 8 Ω 1W Horn |
Pan Tilt Angle | 355 ° Horizontal 90 ° Vertical |
Preview Mode | Full Screen, Half Screen |
Video Output | Main code stream: 1920* 1080@20fps Dynamic control; Secondary code stream: 640* 480@20fps |
Noise Reduction | Support 2D / 3D Noise Reduction |
Day Night Switching | Built In IR-cut Dual Filter |
Light Source | Built In 6 10ml Infrared Lamps |
Minimum Illumination | Color 0 01Lux@F1.2 , Black And White 0.001 Lux@F1.2 |
Wide Dynamic | Support Digital Wide Dynamic |
Video Storage | TF Card, Cloud Storage |
TF Compatible | Micro SD Card: 8g-128g, Freely Replaceable |
Video Recording Mode | Custom Recording Or All Day Recording |
Alarm Mode | App Push Machine Horn Alarm |
Motion Detection | Support Custom Alarm Period Or All Day Period |
Safety Protection | Cryptographic Mechanism |
Fuselage Material | Industrial Plastics ABS |
Night Vision Distance | Infrared Visible Distance: 5-10m; (Varies By Environment) |
Language Support | Support Multiple National Languages |
Mobile Monitoring | Android / Apple IOS / PC Client |
The Power Adapter | DC 5V 1A Standard Power Supply |
Working Environment | Temperature - 0 ℃ - + 50 ℃, Humidity 10% - 95% |
